High Speed Automatic Slitting Cutting Machine

CCD Slitter , 300 Type , Electrode Making

Introducing our premier Electrode Making solution – the Advanced CCD-Equipped Slitter 300 Type, a powerhouse in precision slitting and quality control for electrode manufacturing processes. Engineered to perfection, this system integrates cutting-edge technologies to ensure unparalleled accuracy, efficiency, and material optimization.

Key Functions and Features:

• CCD Detection System:

  At the core of our innovation lies a high-resolution CCD detection system capable of real-time online monitoring of front and back electrode coils. This system swiftly identifies defective pole pieces, automatically labels them, and triggers corrective actions. It also employs an automatic closed-loop correction mechanism to adjust the slitting area with remarkable precision, thereby reducing waste and enhancing product quality.

• Unwinding Mechanism with Smart Controls:

  The unwinding system is fortified with an automatic closed-loop tension control system, ensuring consistent tension throughout the unwinding process. Complemented by AVG trolley docking for seamless material loading and an ultrasonic coil diameter monitoring feature, it guarantees uninterrupted operation, precise material handling, and minimized downtime.

• Advanced Dust Removal System:

  Understanding the importance of a clean production environment, we've integrated a unique negative pressure vacuuming cavity structure equipped with a static elimination device. This dual-action system effectively removes dust particles while neutralizing static charge, preserving the integrity of delicate electrode materials and promoting a safer work environment.

• Independent Edge Material Pulling Mechanism:

  Our system boasts an intelligent edge material handling feature, where both sides of the material are independently pulled with precise tension control. This not only prevents material deformation but also ensures accurate slitting. The separate edge bins automatically collect trimmed edge materials, streamlining the workflow and contributing to a more eco-friendly operation by facilitating recycling or repurposing of scraps.

• CCD Slitter 300 Type for Optimal Performance:

  Specifically designed for electrode production, the 300 Type Slitter brings together all these advanced features into a cohesive unit. It delivers exceptional slitting accuracy, rapid processing speeds, and flexibility to accommodate a wide range of electrode widths and materials, making it a versatile addition to any modern electrode manufacturing facility.

Technical parameters

( The following parameters are for reference only )
